Warning and Error Messages in Power BI Custom Visuals

Warning and Error Messages are crucial to notify a user about a potential error that may occur inside a visual. Warning messages are absolutely useful to make the visual as intuitive as possible. There are many examples where a warning or error message may be needed.

Consider the following use cases:

  1. When a text field is used in a numeric placeholder
  2. When negative values are being used when the visual only supports positive values
  3. When an incorrect calculation has occurred because of null value

There are 2 possible ways to show error messages. One using Power Bi’s default warning message, and the other uses HTML elements (For example Bootstrap). Let us consider the following use case where a warning message needs to be shown when a non-numeric field is added in a numeric field well

  1. Power BI Warning Icon

    To add a display warning, we just need to invoke the displayWarningIcon method residing inside host.
     const measureField = options.dataViews[0].categorical.values[0];
      const isNumeric = measureField.source.type.numeric;
      const fieldName = measureField.source.displayName;
      if (!isNumeric) {
          this.host.displayWarningIcon(
          "Numeric field required.",
          `The ${fieldName} field is a non-numeric field. Please ensure that the Measure Data field is numeric.`
          );
       }

    The result should look something like this.
  2. HTML

    We can use any custom logic with either vanilla HTML or any framework. I will use Bootstrap in this example. Following are the steps needed to show an alert using Bootstrap
      1. Install Bootstrap with NPM
        npm i bootstrap

      2. Add the following CSS in the beginning of visual.less
        @import "../node_modules/bootstrap/dist/css/bootstrap.css";

        .alert {
            position: absolute;
            bottom: 0px;
            width: 90%;
            margin-left: 5%;
            text-align: center;
            animation: fade 3s linear;
            opacity: 0;
            z-index: 5;
          }

          @keyframes fade {
            0%,
            70% {
              opacity: 1;
            }
            100% {
              opacity: 0;
            }
          }

      3. Add the following code in the update method. Please note that there are different types of Alerts that you can check out over here.
        const measureField = options.dataViews[0].categorical.values[0];
         const isNumeric = measureField.source.type.numeric;
            if (!isNumeric) {
              select("#sandbox-host")
              .append("div")
              .classed("alert alert-danger alert-dismissible fade show", true)
              .attr("role", "alert")
              .text(`Please ensure that the Measure Data field is numeric.`);
            }

        The result should look something like this.



Using warning and error messages in the correct scenario can definitely help a improve the UX of your custom visual!
